Product Description

Model           AIE-SMBWM-PCB
Major Technical Characteristics
Type            SMB RIGHT ANGLE FEMALE FOR PCB
Impedance                  50Ω
Frequency Range             DC～4GHz
Center conductor retention force  ≥0.28 N
Insertion Loss                0.30dB/1.5GHz
Disengagement force           8-63N
Voltage Standing Wave Ratio  Straight       ≤1.35/3GHz
Right angle                   ≤1.45/1GHz
Durability(mating)             ≥500(cycles)
Cable                        PCB
Material & Plating
Body  Brass                 Gold plated
Pin contact  Brass            Gold plated
Socket contact  Beryllium-copper Customized)  Gold plated
Resilient contact  Beryllium-copper  Gold plated
Insulator                     PTFE
Crimp ferrule  Copper alloy     Nickel or gold plated
O-ring sealing                 6146 silicone rubber

Price Terms︰ EX-WORK

Payment Terms︰ TT/WU/PAYPAL

Packing︰ 100PCS/CARTON

Lead Time︰ 5-7 DAYS AFTER PAYMENT

Product Image
